Mountz 068002-C TBIH Wrench Handle, Red, Range: 12 - 21 lbf.in / 1.3 - 2.37 Nm



Price: $ 171.00

Mountz TBIH Break-Over Torque Wrench with Interchangeable Head
Interchangeable heads
Torque Ranges: 25 ozf.in - 50 lbf.in

The Mountz TBIH Break-Over Torque Wrench with Interchangeable Head is a small torque wrench ideal for applications with limited space. The flexible preset wrench can adapt to different fastening applications as it is compatible with different head options like open end, box end, flare end, hex key end or a ratchet head.The slim wrench features a tamper-proof internal adjustment. When the TBIH torque wrench achieves torque, the head breaks-over signaling to the operator to stop applying torque to the fastener or bolt. Break-over torque wrenches improve control of the fastening process by reducing the risk of both over and under tightening.


line
Features
line

  • The break-over mechanism minimizes shock to assemblies.
  • Tamper-proof internal adjustment. No external adjustment scale - must be preset using a torque analyzer.
  • "Breaks-over" when preset torque is reached eliminating overtorquing.
  • Six different colored aluminum handles allow for color-coding of specific torque values in production areas.
  • Small and lightweight. Ideal for use in restricted spaces.
  • Interchangeable heads are manufactured with a common centerline so the torque setting remains the same when head sizes are changed.


line
Ranges
line

Torque RangeBlack HandleBlue HandleRed HandleGreen HandleGold HandleSilver Handle
25 - 50 ozf.in / 0.17 - 0.35 Nm068000-A068001-A068002-A068003-A068004-A067999-A
3 - 12 lbf.in / 0.34 - 1.3 Nm068000-B068001-B068002-B068003-B068004-B067999-B
12 - 21 lbf.in / 1.3 - 2.37 Nm068000-C068001-C068002-C068003-C068004-C067999-C
20 - 50 lbf.in / 2.26 - 5.65 Nm068000-D068001-D068002-D068003-D068004-D067999-D


line
Interchangeable Heads
line

Open End

American

ModelSizeModelSize
0681155/64"06810711/32"
0681001/8"0681083/8"
0681809/64"06809813/32"
0681015/32"0681097/16"
0681023/16"0681101/2"
06831413/64"0681119/16"
0681037/32"0681125/8"
06821515/64"06811411/16"
0681041/4"0681133/4"
0681059/32"06809913/16"
0681065/16"0680427/8"

Metric

ModelSizeModelSize
0681593 mm06814612 mm
0682024 mm06814713 mm
0681395 mm06814814 mm
0680465.5 mm06813615 mm
0681406 mm06143016 mm
0681606.5 mm06823717 mm
0681417 mm06822218 mm
0681428 mm06820819 mm
0681498.5 mm06819920 mm
0681439 mm06813821 mm
06814410 mm06820922 mm
06814511 mm

line

Box End

American

ModelSizePt SizeModelSizePt Size
1201/8"6 pt1283/8"12 pt
1215/32"6 pt1297/16"12 pt
1223/16"6 pt1301/2"12 pt
1237/32"12pt1319/16"12 pt
1241/4"6 pt1325/8"12 pt
1259/32"6 pt13311/16"12 pt
1265/16"12 pt1343/4"12 pt
12711/32"12pt

Metric

ModelSizePt SizeModelSizePt Size
3135 mm6 pt15410 mm12 pt
1506 mm12 pt15511 mm12 pt
1517 mm12pt15612 mm12 pt
1528 mm12 pt15713 mm12pt
1539 mm12 pt13717 mm12 pt

line

Flare End

American

ModelSizeModelSize
1881/4"1909/16"
1895/16"32011/16"
1873/8"2353/4"
5537/16"32113/16"
1981/2"

Metric

ModelSizeModelSize
23213 mm35517 mm
19415 mm29819 mm

line

Hex Key

American

ModelSizeModelSize
1750.05"1675/32"
1741/16"1683/16"
1625/64"1697/32"
1633/32"1701/4"
1647/64"1713/8"
1651/8"1727/16"
1669/64"1733/4"

Metric

ModelSizeModelSize
2361.5 mm1843.5 mm
1812 mm1854 mm
1822.5 mm1865 mm
1833 mm


line
Downloads
line

Mountz TBIH Break-Over Torque Wrench with Interchangeable Head - Instruction Manual
Mountz TBIH Break-Over Torque Wrench with Interchangeable Head - Data Sheet

Order Online
Check the items you would like to order then click "Add To Cart". Items typically ship within 1 Week
Product Price
Mountz 068002-C TBIH Wrench Handle, Red, Range: 12 - 21 lbf.in / 1.3 - 2.37 Nm $171.00
Accessories Price
PRESET-MZ Presetting of torque wrench to specific value $72.00
060034 1/4" Hex Ratchet Head for TBIH Wrench $182.00
