Mountz EPT Adjustable Click Wrench



Price: $ 0.00

Mountz EPT Adjustable Click Wrench
Torque Ranges: 20 lbf-in to 750 lbf-ft
Durable & robust for industrial fastening applications

The Mountz EPT Adjustable Click Wrench features an external adjustment torque scale, which allows an operator to quickly adjust the torque setting on the tool as needed for different applications. The cost effective click wrenches are durable and robust for a wide variety of industrial fastening applications.Our EPT adjustable click torque wrench is built with high quality materials to ensure low repair frequency and less repair costs. This adjustable click wrench is ideal for field service, maintenance or production environments.


line
Features
line

  • Supplied with factory calibration cert, ISO-17025 cert is optional
  • Durable and robust for industrial fastening applications.
  • Adjustable torque wrench with a square drive. Bi-directional ratchet head.
  • External dual scale (American & S.I.) Graduation collar on the torque handle.
  • Easy to read laser marked scale.
  • Crafted with strong steel shaft with high corrosion resistance.
  • Lightly knurled non-slip grip.
  • 48 tooth ratchet (for models EPT250i - EPT750F).
    60 tooth ratchet (for EPT100i).
  • Positive lock with spring loaded pull-down ring.
  • Positive "click" can be heard and felt when torque is reached.
  • Additional mechanical design features & benefits

Special Features

FeatureBenefitWhat it means for the End-User
Ratchet HeadGear to gear structure will have better torque performance exceeding the ISO standard.Low repair frequency, less repair cost and longer life.
Cr-Mo One Piece PawlThe steel character of CR-MO provides a high strength pawl.Low repair frequency, less repair cost and longer life.
Heat Treat TubeA heat treatment for tubes will prevent tubes to be bent; a bent tube can cause the inaccuracy of torque and break in tubes.Longer tool life and low repair frequency.
Jumping Square "J-Block"A special controlled machined and heat treated.Longer tool life and low repair frequency.
Aluminum Bronze Cam SetProvides a lower coefficient of friction.Longer tool life and low repair frequency.
Si-Cr SpringMost springs are carbon steel, Si-Cr springs provides more spring stability.Better accuracy, longer tool life and low repair frequency.
HandleThe special ergonomic texture of the knurled handle provides a comfortable with great griping properties.Compare with plastic handle, aluminum handle can be more robust, lighter and be easier to grip


line
Specifications
line

AccuracyEPT100i:6% of setting
EPT250i - EPT750F:4% of setting


line
Torque Ranges
line

ModelItem #RangeGraduation Scale
EPT100i28005020 - 100 lbf-in (2.8 - 11.9 N-m)0.5 lbf-in (0.1 N-m)
EPT250i-D28003350 - 250 lbf-in (6.2 - 28.8 N-m)1 lbf-in (0.1 N-m)
EPT250i-A28003450 - 250 lbf-in (6.2 - 28.8 N-m)1 lbf-in (0.1 N-m)
EPT75F28003515 - 75 lbf-ft (23.7 - 105.1 N-m)0.5 lbf-ft (0.5 N-m)
EPT150F28003610 - 150 lbf-ft (20.3 - 210.1 N-m)1 lbf-ft (1 N-m)
EPT250F28003730 - 250 lbf-ft (47.4 - 345.7 N-m)2 lbf-ft (2 N-m)
EPT400F28003880 - 400 lbf-ft (142.3 - 559.2 N-m)2.5 lbf-ft (2.5 N-m)
EPT550F280039110 - 550 lbf-ft (183 - 779.5 N-m)2.5 lbf-ft (5 N-m)
EPT750F280040150 - 750 blf-ft (237.2 - 1050.6 N-m)5 lbf-ft (5 N-m)

ModelItem #Drive SizeWeightLength
EPT100i2800501/4" Sq. Dr.0.4 lbs (0.18 kg)7 1/2" (193 mm)
EPT250i-D2800331/4" Sq. Dr.0.9 lbs (0.4 kg)9 2/3" (245 mm)
EPT250i-A2800343/8" Sq. Dr.0.9 lbs (0.4 kg)9 2/3" (245 mm)
EPT75F2800353/8" Sq. Dr.2.6 lbs (1.2 kg)16 1/8" (410 mm)
EPT150F2800361/2" Sq. Dr.3.5 lbs (1.6 kg)20 1/2" (520 mm)
EPT250F2800371/2" Sq. Dr.3.5 lbs (1.6 kg)24" (610 mm)
EPT400F2800383/4" Sq. Dr.10.9 lbs (4.9 kg)39 7/8" (1012 mm)
EPT550F2800393/4" Sq. Dr.12.6 lbs (5.7 kg)44 1/4" (1125 mm)
EPT750F2800401" Sq. Dr.14.4 lbs (6.5 kg)48 1/4" (1225 mm)


line
Downloads
line

Mountz EPT Adjustable Click Wrench - Instruction Manual
Mountz EPT Adjustable Click Wrench - Data Sheet

Order Online
Check the items you would like to order then click "Add To Cart". Items typically ship within 1 Week
Accessories Price
Mountz 280050 EPT100i 20 - 100 lbf-in (2.8 - 11.9 N-m) $136.00
Mountz 280033 EPT250i-D 50 - 250 lbf-in (6.2 - 28.8 N-m) $136.00
Mountz 280034 EPT250i-A 50 - 250 lbf-in (6.2 - 28.8 N-m) $140.00
Mountz 280035 EPT75F 15 - 75 lbf-ft (23.7 - 105.1 N-m) $143.00
Mountz 280036 EPT150F 10 - 150 lbf-ft (20.3 - 210.1 N-m) $152.00
Mountz 280037 EPT250F 30 - 250 lbf-ft (47.4 - 345.7 N-m) $184.00
Mountz 280038 EPT400F 80 - 400 lbf-ft (142.3 - 559.2 N-m) $469.00
Mountz 280039 EPT550F 110 - 550 lbf-ft (183 - 779.5 N-m) $537.00
Mountz 280040 EPT750F 150 - 750 blf-ft (237.2 - 1050.6 N-m) $714.00
